01
Eccentric centering
Offsets the mechanism to bring the active work point back toward the rotation center.
AUTHORIZED CHUNQI SALES
Zero-point stability.
Stay focused.
The ChunQi Five-Axis Tilting Vise combines eccentric centering with a low-arc structure to keep the machining center at the focal point, without frequent readjustment of the workpiece or microscope.
Sold and supported by Hong Kong Ze Hong Trade Limited, an authorized ChunQi seller.
Drag to view angles 1/8
Whole vise shown
9.6 kg net weight
THE CORE ADVANTAGE
Move the vise.
Keep the point.
Conventional positioning often forces you to find the work again. ChunQi combines two mechanical ideas so the target stays close to the optical center while the vise moves.
ECCENTRIC + LOW ARC
Zero-point
alignment
alignment
Less re-centering and less refocusing under magnification.
02
Low-arc geometry
Shortens the working distance and keeps the center of gravity low for stable, comfortable control.
Recommended zero reference
With the bench as the reference, the vise is approximately 145 mm high and the recommended XYZ zero plane is approximately 170 mm above the bench. That plane sits approximately 80 mm above the upper moving platform; the jaw height is 55 mm and the maximum body diameter is approximately 186 mm.
- Vise height
- ≈145 mm
- XYZ zero plane
- ≈170 mm
ENGINEERED FOR THE BENCH
Heavy stability.
Fine control.
A 9.6 kg net-weight mold-steel structure gives the vise a planted feel. Linked jaws, three-stage positioning and deep jaw options adapt it to jewelry and metal engraving work.
03
Five-axis positioning
Tilt, rotate and present the work to your hands without giving up a stable base.
04
55 mm deep jaws
Extra vertical reach for taller pieces and bangle-scale work.
05
Linked jaw movement
Both jaws move inward together for balanced, centered clamping.
ADAPTIVE WORKHOLDING
Three positions.
Your own fixtures.
Move the jaw plates between three mounting positions to match the workpiece. The base hole pattern is also open for customer-made fixtures, with hole dimensions and technical guidance available.
Mounting layoutFixture-ready base pattern
Common positionFor smaller everyday work
Medium positionMore opening without losing balance
Wide positionMaximum range for larger work
Need a custom jaw or fixture?Ask us for the mounting-hole dimensions and technical guidance.
REVERSIBLE JAW FACES
Choose the face
for the task.
The multi-hole face works with pins for flexible shapes. The minimal-hole face is better suited to precious-metal work where material recovery matters.
Drag the divider to compare both sides.
MEASURED AND DOCUMENTED
Know the footprint
before it arrives.
The updated drawing shows the production dimensions clearly. Product net weight is 9.6 kg; protective export packing brings the shipment to approximately 11 kg.
- Overall diameter
- 186 mm
- Overall height
- 144.5 mm
- Jaw depth
- 55 mm
- Net weight
- 9.6 kg
- Packed shipment
- ≈ 11 kg
mm · UPDATEDIN THE BOX
Everything needed
to set up.
The shipment includes the complete vise, protective jaw pair, positioning parts, adjustment tools and backup fasteners shown here.
01
Five-Axis Tilting Vise1 complete unit
02
Jaw guard plates1 pair · 3D printed
03
Hex adjustment handwheelH4 · 1 piece
04
Hex keysH2.5 & H3
05
Axis centering guide1 piece
06
Backup fastenersM4-55 / M4-10 / M3-10
07
Base level-reset switch1 piece
MATERIAL & CARE
Built from 136H
mold steel.
136H mold steel offers strong mechanical performance, hardness and acid/alkali resistance. It is less rust-resistant than 304 stainless steel; light surface rust can be removed with WD-40 and regular care.
AUTHORIZED WARRANTY SUPPORTLifetime coverage for the vise body
Bearings are covered for five years. Misuse and accidental damage are excluded. D2O coordinates eligible support and returns as the authorized seller; contact us before returning any part.
BUY FROM AN AUTHORIZED SELLER
Ready for a steadier
working point?
Product price$1,799.00
Temporarily out of stock
View product
Discount codes can be applied at checkout. Import duties and taxes are not included.
Have a coupon?Apply a valid code before payment.
- Airwallex secure online payment
- USD checkout
- Discount codes supported
PROTECTED FOR EXPORT
Packed to arrive
ready for the bench.
A fitted 3D-printed guard protects the controls during international transport. The packed shipment is approximately 11 kg.
TRACKED INTERNATIONAL DELIVERY7–10 daysestimated transit
DHLUPSFedEx
We select the most suitable carrier for the destination. The delivery fee is shown at checkout before payment. Import duty, VAT, remote-area surcharges or local brokerage charges may apply separately.
FAQ
Before you order.
Enter the code on this page or at checkout. Valid fixed-value coupons are deducted before payment. Each coupon may have its own expiry date and usage limit.
We choose DHL, UPS or FedEx according to the destination, service coverage and handling conditions. Tracking information is provided after dispatch. Delivery is estimated at approximately 7–10 business days; final timing depends on local customs clearance and last-mile delivery conditions.
The eccentric and low-arc geometry is designed to keep the active point near the optical center as the vise moves, reducing the need to re-center and refocus. Final behavior also depends on setup, work height and microscope geometry.
